6 Seater Golf Car Electric Sightseeing Bus with 48V 5kw AC Motor
Product Overview
The Electric Golf Car 6 Seats MODEL EDA-E918-E6 is a premium electric vehicle designed for golf courses, resorts, and various commercial applications. Featuring a powerful 48V 5KW AC motor and maintenance-free batteries, this vehicle combines performance with eco-friendly operation.
Specifications
| HS CODE | 8703101900 |
| Qty/20'GP (Assembled) | 1 UNIT |
| Qty/40'HQ (Assembled) | 2 UNITS |
| Qty/20'GP (Disassembled) | 12 UNITS |
| Qty/40'HQ (Disassembled) | 18 UNITS |
Performance
| Passenger capacity | 6 seats |
| Max.Speed | 18-30km/h (adjustable) |
| Range (loaded) | 70km-80km (level road) |
| Climbing Ability | 30% |
| Braking Distance | <6m |
| Min.Turning Radius | 5.5m |
| Recharge time | 8~10h |
Dimensions
| L×W×H | 4045*1210*1960mm |
| F/R Tread | 900mm/1005mm |
| Axle Distance | 3305mm |
| Max. loading | 510 kg |
Standard Configurations
| Motor | 48V/5KW AC motor |
| Controller | 48V |
| Battery | Maintenance-free battery 8V /150Ah*6PCS |
| Body & Roof | Automobile special PP material injection molded parts / Integrated molding roof |
| Windshield | Foldable windshield |
| Seats | Ergonomic seat, leather fabric |
| Rear view mirror | Left and right mirrors |
| Bumper | Front Bumper |
| Tire | 205/50-10'' Turf tire 10 inch rim |
| Chassis | Robotic welding chassis with high-end coating processing, Super strong, No Rust |
| Front Suspension | Double swing arm independent front suspension + spiral spring + cylinder hydraulic shock absorption |
| Rear suspension | Overall rear axle, speed ratio 12.49:1 spiral spring shock absorption + cylinder hydraulic shock + rear stabilizer bar |
| Lighting system | LED front combination light (near light, high beam, turn signal, daily running light, position light) LED rear taillight (brake light, position light, turn signal); snail horn, reversing buzzer |
| Brake system | Double-loop four-wheel hydraulic brake, four-wheel disc brake + electronic brake parking |
| Steering system | Double gear rack steering system, automatic clearance compensation function |
| Charger | Smart on-board charger Output:48V 25A, Input AC 220V/50HZ~60HZ |
| Dashboard | Injection molding instrument panel, electric lock switch, single arm combination switch, gear switch, water cup holder; double USB power supply, 12V power supply |
| Instrument | Multi-instrument |
Color Options
Standard colors: Black, Beige
Optional colors: Ocean Grey, Sapphire blue, Pearl black, Pearl White, Apple Green, Matt Black, Dark Green, Orange, Red
Key Features
- Golf-special plastic materials with high hardness paint layer for durability and shine
- International standard high strength steel chassis designed for automotive applications
- Engineering plastic frame for lighter weight and enhanced vehicle firmness
- Noble and luxury appearance with traditional golf cart design elements
- Electric power steering system for comfortable operation
- High efficiency AC motor for reliable performance
Product Images
Packaging & Shipping
Applications
- Golf Courses
- Hotels
- Campuses
- Parks
- Airports
- Tourist Resorts
- Museums
- Mountain Areas
- Wedding Venues
Frequently Asked Questions
1. What's your warranty time?
All golf carts sold by us are quality guaranteed. We provide 1 year warranty for main parts to our electric vehicles when you get them.
2. What's the production time?
Normally 30 working days.
3. What's your payment term?
T/T 30% deposit and balance paid before shipment.
4. Can we also purchase the parts?
Yes, if you do maintenance service, you can also buy parts from us. We are professional for the aftersales.
5. How do you provide after-sales once customer bought the cart from us?
Once you purchase the cart from us, we will provide you manual to learn it and tell you how to fix it.
6. What is your MOQ?
You can order MOQ 1 unit.
7. Can we put the Logo we designed on the cart?
Yes, you can put your own Logo on the cart.
8. How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers benefit. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
9. Dealer options:
If you can do 100-200pcs in a year, then the next year, we will sign exclusive dealer with you and promise never sold to your dealer area.
